UTP Cat6 Gel Filled Outdoor Cable , Cat6 Direct Burial Ethernet Cable UV Resistant

UTP Cat6 Gel Filled Outdoor Cable , Cat6 Direct Burial Ethernet Cable UV Resistant image

Get a Quote Email to us

Brand Name :
Shenzhen Chengtiantai

Model Number :
Cat. 6 UTP Gel Filled Cable

Certification :
CE,UL& ROHS

Place of Origin :
Guangdong，China（Mainland）

MOQ :
Negotiable

Price :
Negotiable

Payment Terms :
L/C, T/T

Supply Ability :
50,000 m/day

Delivery Time :
7 / 15 working days

Packaging Details :
coil in box or reel

ANSI/ TIA Category :
6

Pairs Quantity :
4

Cable Type :
U/ UTP (unshielding)

Conductor Material :
Solid Bare Copper

Conductor Gauge :
23 AWG (0.56 mm )

Insulation Material :
HDPE

Cable Length :
1000 ft/305 m

Jacket Material :
UV Resistant PE

Cat.6 UTP Outdoor Gel Filled Direct Burial Cable

UTP, 4-pair with rip cord
Polyolefin Jacket, UV Resistant
Gel filled (Non Conductive)
Supports all applications designed to operate over category 6 or lower rated systems.

**Cat6 Gel Filled Outdoor Cable CONSTRUCTIONS**
Number of Pairs	4	Color Code: Pair 1: Blue-White/Blue Pair 2: Orange-White/Orange Pair 3: Green-White/Green Pair 4: Brown-White/Brown Packaging:305m reel in box
Conductor	Solid Copper Ø 0.56 mm
Insulation	HDPE
Separator:	cross filler
screen	PET tape
rip cord (optical)	yes
Water Proof	Gel filled
Outer sheath	uv resistant Linear low-density polyethylene
thickness of outer sheath	0.55 mm
cable outer diameter	6.3 mm
Colour	balck

Length:

Cable weight:

Wire size:

Overall outside diameter:

1000 ft/305 m

14~15 kg

23 AWG (Ø 0.56 mm)

6.3 mm

**Cat6 Gel Filled Outdoor Cable Electrical characteristics**
ANSI/TIA Category Characteristic Impedance (Frequency: 1-200 MHz) DC Resistance Unbalance, maximum DC Resistance , maximum at 20˚C Propagation delay at100 MHz (ns/100m) Delay Skew Mutual Capacitance Nominal Velocity of Propagation (NVP) Coupling attenuation at 30˚C Operating Frequency, maximum	6 100 ± 15 ohms 5 % 9.38 ohms/100 m <536 ≤35 ns 5.6 nF/100 m @ 1 kHz 69% 45MHz(dB) 250 MHz

**Cat6 Gel Filled Outdoor Cable** **Transmission Specifications**
Frequency	Attenuation	NEXT (Min)	PS NEXT (Min)	ELFEXT (Min)	PS ELFEXT (Min)	Attenuation (Max)	TCL (Min)	PS ANEXT (Min)	PS AACR-F (Min)	RL (Min)
MHz	dB/100m	dB	dB	dB/100m	dB/100m	dB	dB	dB	dB	dB
4	4.2	66.3	63.3	56	53	3.8	44	67	66.2	23
8	5.9	61.8	58.8	49.9	46.9	5.3	41	67	60.1	24.5
10	6.6	60.3	57.3	48	45	5.9	40	67	58.2	25
16	8.3	57.2	54.2	43.9	40.9	7.5	38	67	54.1	25
20	9.3	55.8	52.8	42	39	8.4	37	67	52.2	25
25	10.5	54.3	51.3	40	37	9.4	36	67	50.2	24.3
31.25	11.7	52.9	49.9	38.1	35.1	10.5	35.1	67	48.3	23.6
62.5	16.9	48.4	45.4	32.1	29.1	15	32	65.6	42.3	21.5
100	21.7	45.3	42.3	28	25	19.1	30	62.5	38.2	20.1
200	31.7	40.8	37.8	22	19	27.6	27	58	32.2	18
250	35.9	39.3	36.3	20	17	31.1	26	56.5	30.2	17.3
300	39.8	38.1	35.1	18.5	15.5	34.3	/	55.3	28.7	17.3
400	46.9	36.3	33.3	16	13	40.1	/	53.5	26.2	17.3
500	53.4	34.8	31.8	14	11	45.3	/	52	24.2	17.3

Note: Values are expressed in dB per 100 m (328 ft.) length @ 20˚C.

**Manufacturing Process Of Lan cable**

1. copper rod	2. wire drawing	3. Annealing

4. Core insulation	5. Wire twisting	6. wire backing twisting

7. Cabling	8. Jacking	9. Packing

We are China UTP Cat6 Gel Filled Outdoor Cable , Cat6 Direct Burial Ethernet Cable UV Resistant manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
