Single Core XLPE Insulated Cable 600/1000V Rated Voltage IEC 60228

Single Core XLPE Insulated Cable 600/1000V Rated Voltage IEC 60228 image

Get a Quote Email to us

Brand Name :
HOLD-ONE

Certification :
CE/IEC/KEMA

Place of Origin :
China

MOQ :
300m

Price :
USD 1.5-260 Per Meter

Payment Terms :
L/C, T/T, D/P, D/A, Western Union, MoneyGram

Supply Ability :
200km per month

Delivery Time :
9 working days

Packaging Details :
Iron-wooden drum,wooden drum

Rated Voltage :
600/1000V

Insulation Color :
Nature or Customization

Core No. :
1

Conductor :
Stranded Aluminum Conductor

Standard :
IEC 60502-1,IEC 60228

Core Mark :
Color Strip or Number

Cable Mark :
Ink Printing or Embossing

Packing Style :
500 to 1000 meter per drum

600/1000V Single Core XLPE Insulated Power cable Copper Conductor Shanghai Factory

XLPE is suitable for voltage ranges from low to extra high voltage, surpassing other insulation materials such as PVC, Ethylene Propylene Rubber (EPR) and silicone rubbers. Cross-linking the polyethylene also enhances the chemical and oil resistance at elevated temperatures and makes it suitable for use as a Low Smoke Zero Halogen material.

Improved water-tree resistance is another benefit of XLPE insulation for LV cables and MV cables over PE insulations. Water treeing is a defect which is the result of imperfections in the insulation where fracture lines occur and grow in the direction of the electric field, increasing with electrical stress. It should be noted that this effect is not limited to PE materials.

Physical and Electrical Characteristics

No.cores x	Insulation thickness		Sheath	Outer Ø	weight	Current ratings in air 30℃	Current ratings buried 20℃
cross-sec.			thickness	approx.	approx.
			Nominal
	Phase	Neutral	value
mm²	mm	mm	mm	mm	kg / km	A	A
3×4+1×2.5	0.7	0.7	1.8	12.7	277	37	47
3×6+1×4	0.7	0.7	1.8	13.9	363	47	60
3×10+1×6	0.7	0.7	1.8	16.1	527	64	81
3×16+1×10	0.7	0.7	1.8	18.6	766	85	106
3×25+1×16	0.9	0.7	1.8	22.2	1140	113	137
3×35+1×16	0.9	0.7	1.8	24.6	1475	139	164
3×50+1×25	1	0.9	1.8	27.7	1951	173	198
3×70+1×35	1.1	0.9	1.9	31.9	2662	222	246
3×95+1×50	1.1	1	2.1	36.2	3578	271	293
3×120+1×70	1.2	1.1	2.2	39.9	4567	318	334
3×150+1×70	1.4	1.1	2.3	45	5514	370	375
3×185+1×95	1.6	1.1	2.5	49.4	6850	427	422
3×240+1×120	1.7	1.2	2.7	54.9	8741	507	492
3×300+1×150	1.8	1.4	2.9	62.9	11052	599	560

Using features:

XLPE/PVC insulated electrical wire are covering series of wire products, and its working temperature isdifferent according to different insulation materials, mainly 70 and 90 degrees temperature, etc.

According to the conductor type, including solid conductor PVC/XL .PE insulated electrical wire,standed PVC/XL PE insulated wire, Flexible PVC/XLPE insulated wire with different colors.

According to its shape, including flat wire, round wire, etc. with different colors.

Accoding to its core number, including single core wire, multi-core wire, etc. with different colors.

The highest allowed operating temperature of conductor for long-term working is 90oC. In short-circuit(Max. Long-term is no more than 5 seconds). The highest temperature for conductor is no more than250.

D.C Resistance of the conductor complies with the stipulations of GB/T3956-1997.

The environment temperature should be no lower than 0 when lay. Otherwise it should be preheated.The cable is laid without horizontal drop limit. The Min. Bending radius of three core cable should be nosmaller than 12 times of cable outer diameter.

Partial Discharge Test: The discharge volume should be no more than 10pC under 1.73Uo for the cable.

RECOMMENDED ORDERING PARAMETERS

For prompt quotation / supplies please make sure your inquiries and your orders are securing the following data :

1 International or Special Standard. (Alternatively, the precise usage of the cable.)

2 Rated voltage.

3 Copper or Aluminium conductors.

4 Size of each conductor.

5 Insulation material : PVC XLPE or others.

6 Number and identification of conductors.

7 Other requirements.

8 Packing.

9 Required delivery time.

10 Required validity.

If this all seems a litle too technical for you, then why not get in touch with us.We look forward to assisting you in identifying the best products for your specific application and to answer any questions you might have.

We are a manufacture in this filed for many years, we can offer our customers cables with good quality and price.

We Sincerely welcome customers at home and abroad to negotiate and cooperate with us !!!
