Single Core CU / PVC / PVC Low Voltage Copper Cable Nonmetallic Sheath Unarmored Power Cable

Application:
These cables are used for electricity supply in low voltage installation system, They are suitable for installation in indoors and outdoors, in cable ducts, under ground, in power and switching stations, local energy distributions, industrial plants, where there is no risk of mechanical damage.

Construction:
Conductors: Copper or Aluminium conductor, round standed or Shaped, Class 2 to IEC 60228, BS EN 60228. For smaller sizes, a solid round conductor, Class 1 as per IEC 60228, BS EN 60228 can also be supplied upon request.

Standard:
Basic design to IEC 60502-1, IEC 60228,BS EN 60228
China: GB/T 12706.2-2008
Other standards such as BS7870, DIN and ICEA upon request

Certificates:
CE, ROHS,KEMA and more others at request

Insulation:
PVC material and thickness shall be as per IEC 60502 or BS 5467

Noted: Insulation color as per standards or customer requirement.
Colour Code Colour Code (1):
1 Core: Red or Black; 2 Cores: Red, Black; 3 Cores: Red, Yellow, Blue; 4 Cores: Red, Yellow, Blue, Black; 5 Cores: Red, Yellow, Blue, Black, Green; Above 5 Cores: Black Cores with White numerals

Outer Sheath:
Outer sheath shall be of Extruded PVC Type ST2 as per IEC 60502-1 or Type 9 as BS 6346/5467.
Special type of PVC sheathing material such as Fire Retardant PVC, Anti-Termite PVC, Anti-Rodent PVC, Sunlight resistant PVC, Oil Resistant PVC are available on special request. Also, special sheathing materials such as LLDPE, MDPE, HDPE, LSF, CPE are available on request.

Fire Performance of Cable Sheaths:
Cables can be supplied with special flame retardant PVC outer sheath to comply with the flame test requirements of IEC 60332-3-22, IEC 60332-3-23 and IEC 60332-3-24, can also supply cables with Low Smoke Halogen Free (LSHF) material according to IEC 60502-1, BS 7211, BS 6724 or other equivalent standards.

Single Core CU / PVC / PVC Low Voltage Copper Cable Nonmetallic Sheath Unarmored cable NYY Power Cable Parameters:
Single core(unarmoured)

Nominal
Cross
Section

Diameter of Conductor
(Approx.)

Nominal

Insulation
Thickness

Nominal

PVC Sheath
Thickness

Overall

Diameter
(Approx.)

Weight

of Cable
(Approx.)

mm² mm mm mm mm Kg/Km
1×4 2.25 1.0 1.4 7.5 95
1×6 2.76 1.0 1.4 8.0 120
1×10 4.0 1.0 1.4 9.0 165
1×16 5.0 1.0 1.4 10.0 230
1×25 6.3 1.2 1.4 12.0 340
1×35 7.4 1.2 1.4 13.0 450
1×50 8.8 1.4 1.4 14.5 570
1×70 10.6 1.4 1.4 16.0 800
1×95 12.4 1.6 1.5 18.5 1070
1×120 14.0 1.6 1.5 20.0 1200
1×150 15.5 1.8 1.6 22.0 1600
1×185 17.4 2.0 1.7 24.0 1980
1×240 20.3 2.2 1.7 27.0 2560
1×300 22.7 2.4 1.8 30.0 3180
1×400 25.4 2.6 1.9 33.0 4060
1×500 28.8 2.8 2.0 37.0 5140
1×630 30.4 2.8 2.2 42.0 6600

Single core (aluminum wire armoured)

Nominal

Area

Approx

Conductor

Diameter

Nominal

Insulation

thickness

Nominal

bedding

thickness

Nominal

Alum

Wire dia.

Nominal

Sheath

thickness

Approx.

Overall

Diameter

Approx.

Weight

mm2 mm mm mm mm mm mm Kg/Km
1×10 4 1.0 1.0 0.8 1.8 14 300
1×16 5 1.0 1.0 0.8 1.8 15 375
1×25 6.3 1.2 1.0 0.8 1.8 16 500
1×35 7.4 1.2 1.0 0.8 1.8 18 625
1×50 8.8 1.4 1.0 1.25 1.8 20 835
1×70 10.6 1.4 1.0 1.25 1.8 22 1075
1×95 12.4 1.6 1.0 1.25 1.8 24 1385
1×120 14.0 1.6 1.0 1.6 1.8 26 1700
1×150 15.5 1.8 1.0 1.6 1.8 28 2025
1×185 17.4 2.0 1.0 1.6 1.8 31 2450
1×240 20.3 2.2 1.0 1.6 1.9 34 3100
1×300 22.7 2.4 1.0 2.0 2.0 38 3900
1×400 25.4 2.6 1.2 2.0 2.1 42 4875
1×500 28.8 2.8 1.2 2.0 2.2 45 6050
1×630 30.4 2.8 1.2 2.0 2.4 50 7625

Single Core CU / PVC / PVC Low Voltage Copper Cable Nonmetallic Sheath Unarmored cable NYY Power Cable images
