RED H07V-R 25/35/50 Sqmm Single Copper Wire With Stranded Conductor
RED H07V-R 25/35/50 Sqmm Single Copper Wire With Stranded Conductor image
Brand Name :
Zhenglan cable
Model Number :
single copper wire
Certification :
3C，CE, ISO 9001:2015，ISO 14001:2005
Place of Origin :
China
MOQ :
1000 meters
Price :
Negotiable
Payment Terms :
L/C, T/T, , Western Union
Supply Ability :
1500km
Delivery Time :
5~10 days
Packaging Details :
100m/Roll, 90m/roll or as request
Material :
Class 2 Copper
Insulation :
PVC
Application :
for home usage
Conductor type :
bare copper
Running Voltage :
300/500V;450/750V;
Color :
black, red, green, blue, yellow/green
Country of original :
Henan, China
Port :
Shanghai or Qingdao
RED H07V-R 25/35/50sqmm Single Copper Wire With Stranded Conductor
Construction:
Conductor:
solid copper/aluminum class 1 or Stranded copper, class 2
Insulation: PVC
Insulation color: black, red, green, blue, yellow/green
Electrical characteristics:
Rated voltage Uo/U (Um) : 300/500V; 450/750V
Test voltage: 2000V(300/500V); 2500V(450/750V)
Standards:
300/500V—60227IEC05(BV, BLV)/ GB/T5023.3-2008
450/750V—60227IEC01(BV, BLV) / GB/T5023.3-2008
Physical features:
Bending radius: 15 x Ø
Service temperature:+70℃,+90℃,105℃ available
Insulation resistance: 10 MΩ x km
Application: These insulated wires are suitable for laying tubes, under and surface mounting of plasters and also in closed installation conduits. These are not allowed to install for direct laying in cable trays, channels or tanks. These types are permitted for the inner wiring of equipment, distributor and switchboards and also for protective laying to the lightings
Packing: 100m per roll (per coil or plastic reel, as your request)
single core pvc indulated copper wire with RM stranded conductor class 2 CU/PVC BV 4sqmm technical data
450/750V
Core number/sectional area(mm²) |
Core no./diameter(mm) |
Outer diameter(mm) |
Weight (kg/km) |
20℃conductor resistance(Ω/km) |
||
Cu |
Al |
Cu |
Al |
|||
1×1.5(A) |
1/1.38 |
3.2 |
20.3 |
|
12.1 |
|
1×1.5(B) |
7/0.52 |
3.3 |
21.6 |
|
12.1 |
|
1×2.5(A) |
1/1.78 |
3.9 |
31.6 |
17 |
7.41 |
11.80 |
1×2.5(B) |
7/0.68 |
4.0 |
34.8 |
|
7.41 |
|
1×4(A) |
1/2.25 |
4.4 |
47.1 |
22 |
4.61 |
7.39 |
1×4(B) |
7/0.85 |
4.6 |
50.3 |
|
|
|
1×6(A) |
1/2.76 |
5.0 |
50.3 |
29 |
3.08 |
4.91 |
1×6(B) |
7/1.04 |
5.2 |
53.7 |
|
3.08 |
|
1×10 |
7/1.35 |
6.4 |
119 |
62 |
1.83 |
3.08 |
1×16 |
7/1.70 |
7.8 |
179 |
78 |
1.15 |
1.91 |
1×25 |
27/2.04 |
9.7 |
281 |
118 |
0.727 |
1.20 |
1×35 |
27/2.52 |
10.9 |
381 |
156 |
0.524 |
0.866 |
1×50 |
19/1.78 |
12.8 |
521 |
215 |
0.387 |
0.641 |
1×70 |
19/2.14 |
14.4 |
734 |
282 |
0.268 |
0.443 |
1×95 |
19/2.52 |
17.1 |
962 |
385 |
0.193 |
0.320 |
1×120 |
37/2.03 |
18.8 |
1180 |
431 |
0.153 |
0.253 |
1×150 |
37/2.25 |
20.9 |
1470 |
539 |
0.124 |
0.208 |
1×185 |
37/2.52 |
23.3 |
1810 |
666 |
0.0991 |
0.164 |
1×240 |
61/2.25 |
26.6 |
2350 |
857 |
0.0754 |
0.125 |
1×300 |
61/2.52 |
29.6 |
2930 |
1070 |
0.0601 |
0.100 |
1×400 |
61/2.85 |
33.2 |
3870 |
1390 |
0.0470 |
0.0778 |
A–stands for solid annealed copper class 1; B– stands for Stranded copper, class 2
Remarks: Flame retardant, fire resistance (adopt mica tape), low smoking and Halogen free, or other property are available.
ZR cable (flame retardant cable) is the kind of cable with PVC insulation built mixed with fire prevention additive to make it have the capability of preventing or retarding flame spread during combustion.
NH cable (fire resistant cable) is the kind of cable built with a layer of mica tape. Even if the plastic skin is burnt out, refractory layer will help not cause short circuit. When wiring, cut off the refractory layer at the wire head.
LSZH,LSOH,LS0H,LSFH or OHLS cable(Low smoke zero halogen cable) is cable with insulation or outer sheath built using low smoke zero halogen free material to help reduce toxic and corrosive gases produced during combustion.
Termite-proof cable is the cable built with insulation or outer sheath mixed with a kind of materials to prevent termite biting the cable.
