Multi Core Fire Resistant Cable XLPE Insulated PVC Sheathed Copper Core Power

Multi-core fire-resistant XLPE insulated PVC sheathed copper-core power cable

FR – Flame Retardant

Application:Crosslinked polyethylene insulated power cables have excellent thermal-mechanical properties, excellent electrical properties and chemical corrosion resistance. They also have the advantages of simple structure, light weight and no drop restriction. They are widely used in urban power grids, mines and factories.
The insulation-crosslinked polyethylene of cable is a kind of crosslinked polyethylene with linear molecular structure transformed into three-dimensional network structure by chemical and physical methods, which greatly improves the thermomechanical properties of polyethylene and consequently maintains excellent electrical properties.

Technical data

Rated voltage: 0.6-KV

Max. Conductor Temp.: normal (90°C), short circuit no more than 5 s (the highest temperature of conductor shall no more than 250°C )

Min. Ambient Temp.:The cable shall be pre heated if the ambient temperature is below 0°C

Min. Bending Radius: single core cable 20(d+D)±5%

Multi-core cable 15(d+D)±5%

Certificates

CE, RoHS, CCC, KEMA and more others at request

Product Description:
– XLPE insulated PVC sheathed power cable (XLPE/PVC Cable)
– XLPE insulated steel tape armored PVC sheathed power cable (XLPE/STA/PVC Cable)
– XLPE insulated steel wire armored PVC sheathed power cable (XLPE/SWA/PVC Cable)
– Flame retardant XLPE insulated PVC sheathed power cable (FR/XLPE/PVC Cable)
– Flame retardant XLPE insulated steel tape armored PVC sheathed power cable (FR/XLPE/STA/PVC Cable)
– Flame retardant XLPE insulated steel wire armored PVC sheathed power cable (FR/XLPE/SWA/PVC Cable)
