Industrial Rubber Flexible Cable MYP Screen 16mm2 – 185mm2 Phase 0.38/0.66 Voltage
Industrial Rubber Flexible Cable MYP Screen 16mm2 – 185mm2 Phase 0.38/0.66 Voltage image
Brand Name :
HOLD-ONE
Certification :
CE/KEMA/CCC/TUV
Place of Origin :
China
MOQ :
500m
Price :
USD 0.4 To 10.5 per Meter
Supply Ability :
5KM per Day
Delivery Time :
10-15 Days
Packaging Details :
Steel Wooden Drum
Voltage :
0.38/0.66
Phase :
16mm2 to 185mm2
Conducotor :
Flexible Copper
Insualtion :
Rubber
Sheathed :
Rubber
Screnn :
Brain Copper Wire
Industrial MYP Screen Rubber Sheathed Cable , Rubber Electrical Cable
Characteristics
1. Rated power-frequency voltage U0/U: 450/750V, 300/500V and 200/200V.
2. Maximum permitted operating temperature of conductor is 60°C.
3. Permitted lowest working temperature is -35°C.
4. Cables can be used at places contaminated by mineral oil and fuel oil.
Construction:
Conductor: Flexible Class 5 Copper Conductor
Insualtion: Rubber Sheath
Screen: Copper Wire or others
Sheath: Rubber Sheath
Implemented standard
1 For the non-spread combustion cable, implement GB12972
2 For the flame-retardant cable, implement MT818
3 For the special mining cable(with bigger cross-section and higher voltage),implement the enterprise standard.
Type and Name:
Type | Description | Application |
MC-0.38/0.66 | Rubber flexible cable for excavator | As the power connection used in the excavator |
or similar equipment with rated voltage 0.38/0.66kV | ||
MCP-0.38/0.66 | Shielded, rubber-sheathed flexible cable for excavator | As the power connection used in the excavator |
or similar equipment with rated voltage 0.38/0.66kV | ||
MCP-0.66/1.14 | Shielded, rubber flexible cable for excavator | As the power connection used in the excavator |
or similar equipment with rated voltage 0.38/0.66kV | ||
MCPJB-0.66/1.14 | Shielded ,monitoring and braiding reinforced type, | As the power connection used in the excavator |
rubber flexible cable for excavator | or similar equipment with rated voltage 0.66/1.14kV, | |
it can be dragged directly | ||
MCPJR-0.66/1.14 | Shielded ,monitoring and braiding reinforced type, | As the power connection used in the excavator |
rubber flexible cable for excavator | or similar equipment with rated voltage 0.66/1.14kV, | |
it must be used in the protective chain panel | ||
MCPT-0.66/1.14 | Metallic shielded rubber flexible cable for excavator | As the power connection used in the excavator |
or similar equipment with rated voltage 0.66/1.14kV | ||
MCP-1.9/3.3 | Shielded rubber flexible cable for excavator | As the power connection used in the excavator |
or similar equipment with rated voltage 1.9/3.3kV | ||
MCPT-1.9/3.3 | Metallic shielded rubber flexible cable for excavator | As the power connection used in the excavator |
or similar equipment with rated voltage 1.9/3.3kV | ||
MCPTJ-1.9/3.3 | Metallic shielded, monitoring type, rubber flexible cable for | As the power connection used in the excavator |
excavator | or similar equipment with rated voltage 1.9/3.3kV | |
MY-0.38/0.66 | Movable rubber flexible cable for mining | As the power connection used in the mining |
machine with rated voltage 1.9/3.3kV | ||
MYP-0.38/0.66 | Movable shield rubber flexible cable for mining | As the power connection used in the mining |
machine with rated voltage 0.38/0.66kV | ||
MYP-0.66/1.14 | Movable shield rubber flexible cable for mining | As the power connection used in the mining |
machine with rated voltage 0.66/1.14kV | ||
MYPJ-3.6/6 | Monitoring movable shield rubber flexible cable for mining | As the power connection used in the mining t |
ransformer and similar equipment with rated voltage3.6/6kV | ||
MYPTJ-3.6/6 | Metallic shielded monitoring type movable | As the power connection used in the mining |
rubber flexible cable | transformer and similar equipment with rated voltage3.6/6kV | |
MYP-3.6/6 | Movable shield rubber flexible cable for mining | Mining equipment with rated voltage 3.6/6kV |
the min. environment temperature is-20℃ | ||
MYPT-3.6/6 | Movable metallic shield rubber flexible cable for mining | Mining equipment with rated voltage 3.6/6kV |
the min. environment temperature is-20℃ | ||
MYPD-3.6/6 | Movable shield rubber flexible cable for mining | Mining equipment with rated voltage 3.6/6kV |
the min. environment temperature is-40℃ | ||
MYPTD-3.6/6 | Movable metallic shield rubber flexible cable for mining | Mining equipment with rated voltage 3.6/6kV |
the min. environment temperature is-40℃ | ||
MZ-0.3/0.5 | Driller cable for mining | As the power connection of driller with rated |
voltage 0.3/0.5kV | ||
MZP-0.3/0.5 | Driller shielded cable for mining | As the power connection of driller with rated |
voltage 0.3/0.5kV | ||
MYQ-0.3/0.5 | Movable light-type rubber flexible cable for mining | Lighting in the mine, as the power connection |
of the interlock and control signals | ||
used in the transport machine and equipment |
CorexSize | Nominal Thickness | Overall diameter(mm) MY0.38/0.66 |
||||
Phase | Grounding | Control | Insulation | Sheath | Min | Max |
3×16 | 1×16 | 3×4 | 1.5 | 5 | 35.8 | 38.6 |
3×25 | 1×16 | 3×4 | 2 | 5 | 39.7 | 42.9 |
3×35 | 1×16 | 3×4 | 2 | 5 | 43.1 | 46.3 |
3×50 | 1×25 | 3×4 | 2.2 | 5.3 | 48.5 | 51.8 |
3×70 | 1×35 | 3×6 | 2.2 | 5.8 | 55.1 | 58.8 |
3×95 | 1×50 | 3×6 | 2.4 | 6.4 | 62.4 | 66.1 |
3×120 | 1×50 | 3×10 | 2.6 | 6.9 | 68 | 72.5 |
3×150 | 1×70 | 3×10 | 2.6 | 7.3 | 74.5 | 79.5 |
3×185 | 1×70 | 3×10 | 2.8 | 7.5 | 80.7 | 86.1 |
Core Type | Nominal Size | Min Insulation Resistance at 20℃(MΩ.km) | |
No more than 0.66/1.14KV | 1.9/3.3KV | ||
Phase Conducor or Asistant Conductor |
16 | 350 | 1150 |
25 | 300 | 980 | |
35 | 260 | 850 | |
50 | 230 | 740 | |
70 | 210 | 630 | |
95 | 200 | 550 | |
120 | 200 | 510 | |
150 | 180 | 450 | |
185 | 160 | 400 | |
Control Conductor | 4.6.10 | 100 | 100 |
We are China Industrial Rubber Flexible Cable MYP Screen 16mm2 – 185mm2 Phase 0.38/0.66 Voltage manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
