High Precision Octagonal Light Pole 12m High Durability For Area Lighting

 China High Precision Octagonal Light Pole 12m High Durability For Area Lighting supplier

High Precision Octagonal Light Pole 12m High Durability For Area Lighting image

Get a Quote Email to us

Brand Name :Futao
Model Number :LP-039
Certification :ISO 9001
Place of Origin :CHINA
MOQ :2 pieces
Price :$80 – $1000/piece
Payment Terms :L/C, T/T
Supply Ability :1200 pieces every month
Delivery Time :30 – 60 workdays
Packaging Details :40HC or OT, wrap by mat or straw mat
Product Name :steel street lighting pole
Material :Steel tube
Application :Square, Lighting System for stree lighting pole
Thickness :3mm-20mm
Type :Dual-arm/Single-arm
Base plate :300*300*16/320*320*18/350*350*20mm
Shape :Multi-pyramidal
Ground Mounted :base plate or burial
Certificate :ISO9001-2008

High Precision Octagonal Light Pole 12m High Durability For Area Lighting

Product Description

Widely Used 12m Galvanized Steel Round Octagonal Street Light Pole For Area Lighting

Our street lighting poles can be customized in various ways according to our clients’ requests. This includes pole length, spray painted colour, shape of the pole shaft, number and style of cross arms. Please refer to the table below for further details.

Type Street Lamp pole, lamp post, Lamp column, Street Light Pole
Shape Conoid ,Multi-pyramidal,Columniform,polygonal or conical
Material Q235B/A36,minimum yield strength>=235n/mm2
As well as Hot rolled coil from Q460 ,ASTM573 GR65, GR50 ,SS400, SS490ST52
Torlance of dimenstion ±0.02
Design Load in Kg 300~ 1000 Kg appliced to 50cm from the to pole
Surface treatment

Hot dip galvanized Following ASTM A 123, color polyester power or any other

standard by client required.

Standard Octagonal tapered column
Conforms to Standard:
Pole design : BS EN 40
Material : BS EN 10025 S275 / JIS G3101 SS400
Welding : BS 5135
Galvanizing : BS 729 / ISO 1461 ASTM A 123
Length of per section Within 14m once forming without slip joint.
Suit for Highway
Roadway
Residential subdivisions
Commercial development
Option Height from 6m to 12m
Flange mounted or planted type
Variable arm length from 0.125m to 3.0m with single or double arm type
Variable spigot size from 35mm to 60mm.
Production Process

Raw material test → Cutting →Molding or bending →Welidng (longitudinal )→

Dimension verify →Flange welding →Hole drilling →Calibration → Deburr→

Galvanization or powder coating ,painting →Recalibration →Thread →Packages

Packages

Our poles as normal cover by bubble pack/blanket or straw bale at the top and

bottom ,anyway also can following by client required

Warranty At least 20 years.

Specific Details


Production Flow


Verification of Materials → Cutting → Molding or Bending → Vertical Welding → Verification of Dimensions → Flange Welding → Hole Drilling → Calibration → Deburr Process → Galvanizing, Powder Coating or Painting → Recalibration → Threading → Packaging

Packaging & Shipping


We cover the top and bottom parts of the pole with a mat or straw bale in order to protect it from damage to the galvanized surface that may occur during transportation. Packaging can also be done according to clients’ requirements.

FAQ

Q1. How can I get a price of needed pole?

A: 1. Please provide exact dimensions such as height, pole shaft material type and thickness, top and bottom diameters. We can then give you an accurate quotation based on your specifications.

2. You can send us a detail and assembly drawing; we can then provide you with an accurate quotation based on the drawing.

Q2. I am a small wholesaler; do you accept a small order?
A: It's not a problem if you are a small wholesaler; we accept orders of various quantities.
Q3. I am a designer; Can you help me to produce the sample which we designed?
A: Our mission is to help our customers be successful. We are more than happy to help you solve any problems that you may have.
Q4: We want be your agent for our area. How do I apply for this?
A: Please send your proposal and your company profile.
Q5. Tell me about your company?
We have been a manufacturer and exporter of all kinds of steel poles including power poles, street lighting poles, telecommunications poles and other steel based products since 2000. Our products have been exported to many regions around the world.
Q6. Do you have some special policies for Branded companies?
A: Yes, we have some special support for the company who has own brand but are also in our VIP customers list. Please send us a copy of your sales data so we can analyze the best course of action in supporting you for your products in your market.
Q7. Do you provide Door to Door service? Because i don't know how to deal with customs clearance.
A: We provide Door to Door service to help you reduce shipping time and costs. This is because we have additional discounts with the shipping companies as we have done many shipments in the past. This in turn will save you lots of time and money.
