Galvanized Steel Frame Nylon Conductor Pulley 660x100mm
Galvanized Steel Frame Nylon Conductor Pulley 660x100mm image
Brand Name :
Suntech
Model Number :
SHDN660X100
Certification :
ISO,CE
Place of Origin :
Ningbo,China
MOQ :
1 pcs
Price :
Negotiation
Payment Terms :
L/C, T/T,Western Union
Supply Ability :
1200pcs per month
Delivery Time :
9-15 days after payment
Packaging Details :
Standard export package
Model :
SHDN660X100
Frame :
Galvanized Steel
Bundles :
2 or 4 Lines
Application :
Overhead Line Work
Warranty :
One Year
Approved :
ISO
660X100mm Galvanized Steel Frame Overhead Line Construction Tools Conductor Nylon Pulley
660×100 White Nylon Pulleys for String Two or Four Bundled Conductor Lines
Quick details:
1. Transmission Line Stringing Accessories
2. Two or Three Bundled Conductor Lines
3. Customizable Wheels
4. Nylon Wheels
5. Galvanized Steel Frame
6. Diameter: 660mm
7. Wheel Width: 100mm
8. With Rubber Covered or Without
9. Rated Load: 40kN
10. Conductor Size: under 500mm2
11. Lingsheng Brand
Specification:
660×100 Cream-colored Nylon Pulleys are suitable for string two or three bundled conductor lines
| Performance Model | Wheel size DiameterxWidth(mm) | Conductor Size (mm2) | Rated load (kN) |
Weight (kg) |
Wheel material |
| SHS-508×75 | 508×75 | ≤400 | 40 | 85.5 |
Middle Steel Two Nylon |
| SHS-660X100 | 660×100 | ≤500 | 20 | 106 | |
| SHSN-508×75 | 508×75 | ≤400 | 40 | 60 | Nylon |
| SHSN-660×100 | 660×100 | ≤500 | 40 | 85 | |
| SHSN-822×110 | 822×110 | ≤630 | 60 | 100 | |
| SHSN-916×110 | 916×110 | ≤800 | 80 | 140 | |
| SHSN-1040×125 | 1040×125 | ≤1000 | 110 | 210 | |
| SHSNN-255×110 | 255×110 | ≤630 | 50 | 120 | |
| SHSNN-325×150 | 325×150 | ≤1520 | 120 |
165 |
We are China Galvanized Steel Frame Nylon Conductor Pulley 660x100mm manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
Tags: 660x100mm conductor pulley, galvanized steel frame conductor pulley, nylon conductor pulley, Transmission Line Stringing Tools
