Galvanized GSM Antenna Monopole Telecommunication Steel Tower
Galvanized GSM Antenna Monopole Telecommunication Steel Tower image
Brand Name :
Suntech
Model Number :
Monopole Tower
Certification :
ISO
Place of Origin :
China
MOQ :
1 Tower
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
60000 Metric Ton/Metric Tons Per Year
Delivery Time :
35 days after deposit
Packaging Details :
Exported Containers
Product Name :
Telecommunication Tower
Application :
Mobile Communication tower
Operation Temperature :
-25°C~+55°C
Material :
ASTM A36,ASTM A572 GR65, GR50, Etc.
Usage :
Straight Pole ,Tensile Pole ,Turn Pole
Warranty :
Long Term Warranty Also Available
Galvanized Gsm Antenna Q355 Monopole Telecommunication Steel Tower
The technical parameters meet the following standard:
Design wind speed: 30M/S (varies by regions)
Icing depth: 5mm-7mm: (varies by regions)
Aseismatic intensity: 8°
Preference temperature: -35℃~45℃
Vertical missing: <1/1000
Ground resistance: ≤4Ω
Preservative treatment:
The steel member of the tower is treated with hot dip galvanized anti-corrosion technology,which ensures the tower doesn’t get rusted within 35 years.
Main functions of the communication tower: to support signal transmitting antenna.
| Single pipe tower antenna monopole communication tower | |
| Brand | Suntech |
| Material | Q355/Q345/Q235/Q420 steel |
| Surface treatment | Hot dip galvanized/painting |
| Height | 1-80m, also can customized as buyer’s requirements |
| Wind speed | 30-50m/s, also can customized as buyer’s requirements |
| Payload | 500kg, also can customized as buyer’s requirements |
| Connection type | Flange |
| Service life | More than 30 years |
| Application | Park, uptown, playground, street, etc |
| Standard | GB |
| Certification | ISO9001 |
| Delivery time | Within 20 days or depend on the quantity of pole |
| OEM | OK |
| Welding | Standard | Standard Title |
|
Pole shafts&multi-sided tubular Cross arms&all accessories |
AWS D1.1/D1.1M:2010 | Structural Welding Code-Steel |
| Welding wire | AWS D1.1/D1.1M:2010 | Structural Welding Code-Steel |
| Hot dip galvanizing | Standard | Steel thickness/mm | Mean coating thickness/μm | Metallic element | Content |
| Pole shafts,cross arms&bolted on accessories | ASTM A123/A123M-15 AS/NZS 4680 | >6 | 85 |
Mn
|
0.25%-0.40%
|
| <3-6 | 70 | ||||
| 1.5-3 | 55 |
Cu
|
<0.15%
|
||
| <1.5 | 55 | ||||
| Bolts,nuts&washers |
GB/T 5267.3-2008 (ISO 10684-2004) |
_____ | ≥ 54 | P |
<0.025%
|
| Foundation bolts | ASTM A153/A153M-09 | _____ | ≥ 54 |
S
|
<0.03% |
Production Process
Here is fabrication process for our transmission tower; however, both parties must discuss all drawings and confirm all shop drawings, technical specification, and which standard to conform. Before mass production, we must received all signed approved shop drawings and technical documents from our client.
Our Fabrication shall be in strict accordance with detail Drawings prepared by the Contractor and approved by the Engineer. Fabrication shall begin after the approval of the shop assembly and tests.
We are China Galvanized GSM Antenna Monopole Telecommunication Steel Tower manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
