Durable Overhead Line Conductor Steel Core Transmission Line Standard Size
Durable Overhead Line Conductor Steel Core Transmission Line Standard Size image
Brand Name :
TANO CABLE
Model Number :
ACSR Rabbit Conductor
Certification :
ISO CE CCC
Place of Origin :
CHINA
MOQ :
1000 Meters
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, T/T
Supply Ability :
300KM Per Month
Delivery Time :
15-30 days upon order quantity
Packaging Details :
By wooden drum/reel, steel-wooden drum/reel, steel drum/reel with strong protection to suit for the long-distance delivery.
Application :
overhead
Conductor material :
aac aaac acsr
Type :
High Voltage,Low Voltage,Medium Voltage
Jacket :
None,no jacket
Product name :
ACSR cable,AAC/ACSR/AAAC
Packing :
Steel; Drum
ACSR Aluminum Conductor Steel Core Transmission Line Standard
AAAC, ACSR form part of the family of Overhead Conductors, Transmission Conductors and Power Distribution Conductors. These cables are formally known as All Aluminium Conductor (AAC), All Aluminium Alloy Conductor (AAAC) and Aluminium Conductor Steel Reinforced (ACSR). These overhead conductors are used as power transmission and distribution lines. All aluminium conductors are made up of one or more strands of aluminium wire depending on the specific application..
Application
ACSR is applied for overhead power transmission line
Standard
GB/T1179, IEC61089, ASTM B231, ASTM B399, BS215-1, BS3242 , DIN48201,BS EN 50182etc.
Construction
Construction Parameters
ACSR Technical Characteristics Based on Standard BS 215-2
| Code name | Nominal aluminium area | Stranding and wire diameter | Sectional area of aluminium | Total sectional area | Approx. overall diameter | Approx. mass | Calculated D.C. resistance at 20oC | Calculated breaking load | |
| Al | Steel | ||||||||
| mm2 | No./mm | mm2 | mm2 | mm | kg/km | Ω/km | kN | ||
| RABBIT | 50 | 6/3.35 | 1/3.35 | 52.88 | 61.7 | 10.05 | 214 | 0.5426 | 18.35 |
| DOG | 100 | 6/4.72 | 7/1.57 | 105 | 118.5 | 14.15 | 394 | 0.2733 | 32.7 |
| WOLF | 150 | 30/2.59 | 7/2.59 | 158.1 | 194.9 | 18.13 | 726 | 0.1828 | 69.2 |
| DINGO | 150 | 18/3.35 | 1/3.35 | 158.7 | 167.5 | 16.75 | 506 | 0.1815 | 35.7 |
| LYNX | 175 | 30/2.79 | 7/2.79 | 183.4 | 226.2 | 19.53 | 842 | 0.1576 | 79.8 |
| ZEBRA | 400 | 54/3.18 | 7/3.18 | 428.9 | 484.5 | 28.62 | 1621 | 0.0674 | 131.9 |
Production Description
Factory:
We are China Durable Overhead Line Conductor Steel Core Transmission Line Standard Size manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
