CU/EPR/CPE 3 Conductor Type GGC Cable Round Portable Mining Power Cable 2000V

CU/EPR/CPE 3 Conductor Type GGC Cable Round Portable Mining Power Cable 2000V image

Get a Quote Email to us

Model Number :Type G-GC Mining Cable

Certification :ISO9001, CE

Place of Origin :Henan, China

MOQ :1000m

Price :$1 – $60/ Meter

Payment Terms :L/C, T/T, Western Union

Delivery Time :1-4 weeks

Packaging Details :Roll/Wooden Reel/Iron-wooden Reel/Steel Reel

Type :Insulated

Conductor Type :Stranded

Application :Underground

Conductor Material :Copper

Sheath Material :CPE

Insulation Material :EPR

CU/EPR/CPE 3-CONDUCTOR Type G-GC Mining Round Portable Cable 2000V

Product Description

Application

Standards:

ICEA S-75-381/NEMA WC 58

Cable Construction:

Technical Characteristics:

Maximum operating voltage: 2 kV

Data Sheet

Conductor Size	Number of Strands	Size of Each Strand	Nominal Insulation Thickness	Ground Conductor Size	Maximum Overall Diameter	Approximate Total Weight
AWG or kcmil	–	AWG	mil	AWG	in	lb/kft
8	133	29	60	10	1	652
6	133	27	60	10	1.08	800
4	259	28	60	8	1.22	1082
2	259	26	60	7	1.37	1458
1	259	25	80	6	1.54	1848
1/0	259	24	80	5	1.69	2251
2/0	329	24	80	4	1.79	2681
3/0	413	24	80	3	1.94	3232
4/0*	532	24	80	2	2.09	3642
250*	608	24	95	2	2.45	4556
300*	741	24	95	1	2.62	5389
350*	855	24	95	1/0	2.74	6095
500*	1221	24	95	2/0	3.09	7916

Packing&Shipping

Packing material:

Coil (For small size & short length), Wooden Drum, Iron-Wooden Drum, Steel Drum.

Shipping:

Loading port from Qingdao or Shanghai, 12-24 hours from facotry to sea port.

We are China CU/EPR/CPE 3 Conductor Type GGC Cable Round Portable Mining Power Cable 2000V manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
