Copper Conductor Electric Power Cable , YJV XLPE Insulated Power Cable
Copper Conductor Electric Power Cable , YJV XLPE Insulated Power Cable image
XLPE Insulated Power Cable Electric Copper Conductor Cable Outstanding Mechanical And Thermal Properties
Low Voltage Power Cable 0.6/1 kV 4+1 Core XLPE Insulated, PVC Sheathed, Unarmoured & STA Armoured to IEC 60502
Product introduction of electric copper conductor wires & cables:
Place of Origin: China Mainland
Brand Name: Shenzhen Chentiantai Cable
No. Of Conductor: 4+1Core
Insulation: XLPE
Sheath: PVC Compound
Conductor Material: Bare Copper Class 2
Application of XLPE power cable
IEC 60502-1 XLPE Insulated copper cable are used for electricity supply in low voltage installation system, IEC 60502-1 XLPE Insulated copper cable are suitable for installation in indoors and outdoors, in cable ducts, under ground, in power and switching stations, local energy distributions, industrial plants, where there is no risk of mechanical damage.
Product Specification:
LV Power Cable copper core XLPE Insualed cable 3 Core+ Earth
| No. Cores *cross -sec. |
Insulation thickness |
Nominal Sheath thickness |
Outer Ø approx. |
Weight Approx. |
Current ratings in air 30℃ |
Current ratings Buried 20℃ |
|
| Phase | Neutral | ||||||
| mm² | mm | mm | mm | kg / km | A | A | Ω/km |
| 4×4＋1×2.5 | 0.7 | 0.7 | 1.8 | 14.2 | 320 | 38 | 48 |
| 4×6＋1×4.0 | 0.7 | 0.7 | 1.8 | 15.6 | 427 | 48 | 60 |
| 4×10＋1×6.0 | 0.7 | 0.7 | 1.8 | 18.1 | 636 | 66 | 81 |
| 4×16＋1×10 | 0.7 | 0.7 | 1.8 | 20.8 | 941 | 88 | 107 |
| 4×25＋1×16 | 0.9 | 0.7 | 1.8 | 24.9 | 1441 | 118 | 137 |
* The ampacity of cable will be directly affected by the lay-out methods and the ambient temperature.
Features:
| Rated Voltage UO/U | 0.6/1KV |
| Maximum operating voltage | 1.2 KV |
| Frequency | 50Hz |
| Test voltage | 3500 V |
Advantage:
As a cross-linked polyethylene insulated PVC sheathed power cable, YJV cable not only has outstanding mechanical and thermal properties, but also has excellent electrical properties and corrosion resistance. The internal structure is simple and its weight is light, so it is not limited by the geographical drop when laying. These advantages make YJV cable widely used in urban power grid facilities, as well as many factories.
Other Information:
Packaging Details: Coil in foil
Delivery Time: 15 working days
Payment Terms : L/C, T/T
Applicable Standards of XLPE Insulated copper cable
– IEC 60502-1 Design and Test Guidelines
– IEC 60228 Conductor
– IEC 60332-1 Flame Retardant
– IEC 60332-3-24 Flame Retardant Cat. C
