ASTM 20 AWG 2 Core THHN Electrical Cable Insulated Wire Cable With UL Certificate

ASTM 20 AWG 2 Core THHN Electrical Cable Insulated Wire Cable With UL Certificate image

Get a Quote Email to us

Brand Name :
SHANCABLE

Model Number :
THHN

Certification :
ISO,CE,IEC,TUV,KEMA

Place of Origin :
Shanghai, China

MOQ :
Negotiable

Price :
Negotiable

Payment Terms :
L/C, T/T

Supply Ability :
100KM/Week

Delivery Time :
10 Days

Packaging Details :
Wooden Drum

Outer Jacket :
Nylon

Standard :
ASTM

Insulation :
PVC

Conductor :
Flexible Copper

Sample :
Free

Rated Voltage :
300/500V

ASTM 20 AWG 2Core THHN Electrical Cable With UL certificate China manufacturer

Construction

Multi-cores PVC insulation and sheathed cables with flexible copper conductor for general purposes

Rated voltage	450/750V 300/500V
Maximum Conductor Temperature	Under normal (75℃), emergency (130℃) or short circuit no more than 5 s (160℃) conditions
Min. Ambient Temp	0 ℃, after installation and only when cable is in a fixed position
Min. Bending Radius	15 x cable O.D for multi core without armor

Applications

In dry rooms, apparatus switch and distribution boards, for fixed installation in conduits, over and under plaster and on insulated supports over plaster. Direct laying in plaster is not permitted.

Standards
International: IEC 60227
China: GB/T 5023-2008
Other standards such as BS,DIN and ICEA upon request

Technical data
Rated voltage: 450/750 V
Max. Conductor Temp. in normal use: 70℃
Min. Bending Radius: 4 x cable O.D
Certificates
CE, RoHS, CCC, KEMA and more others at request

Technical parameter

Cross section of conductor	Thickness of insulation	Thickness of Sheath	Approx.cable diameter	Max.resistance of conductor at 20 ℃	Test Voltage(AC)
mm2	mm	mm	mm	ohm/km	KV/5min
3×1.5	0.8	1.8	10.9	12.1	3.5
3×2.5	0.8	1.8	11.8	7.41	3.5
3×4	1.0	1.8	13.7	4.61	3.5
3×6	1.0	1.8	14.8	3.08	3.5
3×10	1.0	1.8	17.6	1.83	3.5

2×1.5	0.8	1.8	10.5	12.1	3.5
2×2.5	0.8	1.8	11.3	7.41	3.5
2×4	1.0	1.8	13.1	4.61	3.5
2×6	1.0	1.8	14.1	3.08	3.5
2×10	1.0	1.8	16.7	1.83	3.5
2×16	1.0	1.8	18.8	1.15	3.5

Packing & Shipping

All cable For exporting are well packed and protected by wooden drum or Wood and Steel Drum.

The packing material is depended on the weight and size of cable.

The good information, manufacture information, and the client's information is firmly printed on each size of drum.

After the well packed cable drums sent to Sea Port, they are loaded into 20 FT container or 40 FT container. All cable drum are firmly fixed by safety belt to make sure, no movement during the sea freight.

The size of the container is chosed according to weight of total loaded goods or as per the client's requirement.

Our Services

♦ We are the one of biggest manufacture of electric wire and power cable in southwest of China and has more than 20 years producing and marketing experience.

♦ We accept OEM. The cable size and material are customized.Ur own logo and

own design are welcome. We will produce according to your requirement and description;

♦ Please send us inquiry for more products info and we will give you feedback in 12 hours.

FAQ
1. Shipping: By sea or air due to heavy weight. Samples will be send by DHL, Fedex. etc
2. Payment: We accept T/T, L/C , just choose what you like
3. Delivery time: Generally 7~10 working days upon receipt deposit. According to the quantity.
4. MOQ: Generally our MOQ is 1000meters. samples below 20 centimeter can be provided freely.

We are China ASTM 20 AWG 2 Core THHN Electrical Cable Insulated Wire Cable With UL Certificate manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
