450/750V Flexible Conductor Multicore Control Cable IEC 60227-2007 Standard
450/750V Flexible Conductor Multicore Control Cable IEC 60227-2007 Standard image
Brand Name :
yifang
Model Number :
KVVP2 KVVP KVV32
Certification :
CE KEMA UL
Place of Origin :
China
MOQ :
500 meters
Supply Ability :
50000 km per year
Delivery Time :
20 days
Packaging Details :
Wooden drum steel-wooden drum all steel drum
450/750V Flexible Conductor Multicore Control Cable IEC 60227-2007 Standard
1. Specification
| Application | Suitable for the interconnection in controlling, protecting and measuring system |
| Number of core | 2~61 cores |
| Rated Voltage |
450/750V conform to IEC 60227-2007 600/1000V conform to IEC 60502-2004 |
| Test Voltage | AC 3000V/5Min for 450/750V, AC 3500V/5Min for 600/1000V |
|
Maximum conductor operating temperature |
90oC for XLPE insulation 70oC for PVC insulation |
| Core's recognition |
Up to 5 core with color Above 5 cor with number |
| Color of sheath | Black and customer designated |
| Manufactured Sdandards | IEC 60227-2007, IEC 60502-2004 |
| Conductor type |
IEC 60228-2004 class 1, class 2 and class5 Nominal Cross-section area:0.5~10mm2 We can produce according to your need and provide technical data. |
| Packing | Cable can be supplied in any length required. |
PVC, XLPE Insulation/Copper tape shield/Unarmoured/PVC, PE and LOSH sheathPVC, XLPE Insulation/Unshield/Unarmoured/PVC, PE and LOSH sheath
PVC, XLPE Insulation/Braiding shield/Unarmoured/PVC, PE and LOSH sheath
PVC, XLPE Insulation/Unshield/Galvanized steel tape armoured/PVC, PE and LOSH sheath
PVC, XLPE Insulation/ Copper tape shield/Galvanized steel tape armoured/PVC, PE and LOSH sheath
PVC, XLPE Insulation/Unshield/Galvanized steel wire armoured/PVC, PE and LOSH sheath
PVC, XLPE Insulation/ Copper tape shield/Galvanized steel wire armoured/PVC, PE and LOSH sheath
2.Type & Name of Cable
| Type | Description | Main applications |
| KVV | Copper core PVC insulated and sheathed control cable | For laying indoor, in tunnels, ducts, conduit etc.permanent place |
| KVVP | Copper core PVC insulated and sheathed copper wire braiding shielded control cable | For laying indoor, in tunnels, ducts, conduit etc.permanent place where shield required. |
| KVVP2 | Copper core PVC insulated and sheathed copper tape shielded control cable | For laying indoor, in tunnels, ducts, conduit etc.permanent place where shield required. |
| KVV22 | Copper core PVC insulated and sheathed steel tape armoured control cable | For laying indoor, in tunnels, ducts, conduit and direct burial etc. Permanent place, able to bear greater mechanical force |
| KVV32 | Copper core PVC insulated and sheathed steel wire armoured control cable | For laying indoor, in tunnels, ducts, conduit and direct burial etc. Permanent place, able to bear greater mechanical force |
| KVVR | Copper core PVC insulated and sheathed flexible control cable | For laying indoor, and flexible and shield required etc.place, easy to move |
| KVVRP | Copper core PVC insulated and sheathed copper wire braiding shielded flexible control cable | For laying indoor , and flexible and shield required etc.place ,easy to move |
| ZR-KVV | Copper core PVC insulated and sheathed flame-retarding control cable | For being applied on heat engine and heat controlling appliance |
We can also supply the OEM and customized products according to your request.
We are China 450/750V Flexible Conductor Multicore Control Cable IEC 60227-2007 Standard manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
