3 Core Xlpe Power Cable Copper Conductor Medium Voltage Armored Ground Wire
3 Core Xlpe Power Cable Copper Conductor Medium Voltage Armored Ground Wire image
Brand Name :
Huanghe
Model Number :
XLPE Insulated Copper Cable
Certification :
IOS OHSAS CCC IEC
Place of Origin :
China
MOQ :
200
Payment Terms :
TT/Western Union /LC
Supply Ability :
50000meters per week
Delivery Time :
5-8days
Packaging Details :
wooden drum
Conductor Core :
Copper
Insulation Material :
Cross Linked Polyethylene (XLPE)
Outer Sheath Material :
XLPE
Armoured Type :
armoured or Unarmored
Cross Section Area :
0.75mm2 to 1000mm2
Standards :
IEC60502, GB/T12706, VDE, UL
Colour :
Customized
Application :
Construction, Power Station
3 Core Xlpe Power Cable Copper Conductor Medium Voltage Armored Ground Wire
The maximum operating temperature of cores shall not exceed 90 ℃ when the cable is used for long perod.
The temperature of cores shall not exceed 250 ℃ at short circut for S seconds. The amlient temperature should
not be below O℃ during installation.
The permissible bending radirs for cable shall be the permissible bending radius for cable shalbecomplied .
with the regulation as below:
For single-core No armoured cable:R>20(D+d) ±5% For multi-core:R>15(D-d)±5%
Armouredd cable:R>15(D+d)±5% For multi-core:R>12(D+d)±5%
Where:R-bending radius(mm) D-overall diameter of the cable(mm)
d-diameter of conductor(mm)
The single core cable of using in AC circuit shall be without armor or with steel wire armour an shall not be
laid in magnetic ducts.
3 Core Copper Conductor Medium Voltage Armoured XLPE Insulated Power Cable
| tem | Single core | Three cores | ||
| Non armor | With armor | Non armor | With armor | |
| Min bending radius during installation | 20D | 15D | 15D | 12D |
|
Near joint box or cable terminal, bending with care and use templet |
15D | 12D | 12D | 10D |
| Note:D is the diameter of cable | ||||
| ype | Designation | Applications |
| YJV |
Copper conductor,XLPE insulated,PVC sheathed power cable |
For laying indoors,in tunnel or cable trench,unable to bear external mechanical forces.Single core cable is not allowed to laid in magnetic duct. |
| YJLV |
Aluminum conductor,XLPE insulated,PVC sheathed power cable |
|
| YJY |
Copper conductor, XLPE insulated,PE sheathed power cable |
|
| YJLY |
Aluminum conductor, XLPE insulated,PE sheathed power cable |
|
| YJV22 |
Copper conductor,XLPE insulated,steel tape armoured,PVC sheathed power cable |
For laying indoors,in tunnel in cable trench,or direct in ground,able to bear external mechanical forces.Single core cable is not allowed to laid in magnetic duct. |
| YJLV22 |
Aluminum conductor,XLPE insulated,steel tape armoured,PVC sheathed power cable |
|
| YJV23 |
Copper conductor,XLPE insulated,steel tape armoured,PE sheathed power cable |
|
| YJLV23 |
Aluminum conductor,XLPE insulated,steel tape armoured,PE sheathed power cable |
|
| YJV32 |
Copper conductor,XLPE insulated,steel wire armoured,PVC sheathed power cable |
For laying indoors,in tunnel cable trench,well or direct in ground,able to bear external mechanical forces and certain pulling force. |
| YJLV32 |
Aluminum conductor,XLPE insulated,steel wire armoured,PVC sheathed power cable |
|
| YJV33 |
Copper conductor,XLPE insulated,steel wire armoured,PE sheathed power cable |
|
| YJLV33 |
Aluminum conductor,XLPE insulated,steel wire armoured,PE sheathed power cab |
3 Core Copper Conductor Medium Voltage Armoured XLPE Insulated Power Cable
We are China 3 Core Xlpe Power Cable Copper Conductor Medium Voltage Armored Ground Wire manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
