2 Core Copper Conductor Flexible Electrical Cable Shield Wire PVC 1mm 2.5mm 4mm RVVP Cable
2 Core Copper Conductor Flexible Electrical Cable Shield Wire PVC 1mm 2.5mm 4mm RVVP Cable image
Brand Name :
JHY CABLE
Model Number :
RVVP cable
Certification :
CCC/ CE/ ISO
Place of Origin :
SHENZHEN CHINA
MOQ :
1000m
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
70 kilometer/ day
Delivery Time :
5~7 working days
Packaging Details :
100 meters per roll or according to the customer’s request.
Conductor :
Stranded class 5 plain copper wire
Size :
2 x 0.5~10mm2
Insulation :
PVC insulation
Color :
red, blue,green, yellow or others
Sheath :
PVC sheath
Shield :
AL + TC braided
Application :
Electric appliance,LED lighting.construction
2 core copper conductor shield wire PVC electrical 1mm 2.5mm 4mm RVVP cable
Production Description:
1. Specifications
- Conductor: stranded flexible copper
- Cores: 2-10 cores
- Insulation: flame retardant PVC
- Insulation Color: red, brown, black ,yellow ,green, etc.
- Shield : single shielded: AL foil; double shieded: AL foil+braid
- Sheath: PVC
- Rated voltage: 300/300V, 300/500V
2. Product Technical data
|
Nominal cross-section (mm2) |
Insulation thickness (mm) |
Reference overall diameter (mm) |
Conductor resistance at 20℃ (Ω/km) |
Minimum insulation resistance at 70 ℃ (MΩ·km) |
Reference weight (kg/km) |
| 2×0.5 | 0.6 | 6.0 | 39.0 | 0.012 | 48.3 |
| 2×0.75 | 0.6 | 7.0 | 26.0 | 0.010 | 63.2 |
| 2×1.0 | 0.6 | 7.5 | 19.5 | 0.010 | 73.0 |
| 2×1.5 | 0.7 | 8.4 | 13.3 | 0.009 | 92.9 |
| 2×2.5 | 0.8 | 9.0 | 7.98 | 0.008 | 136.5 |
| 2×4 | 0.8 | 11.8 | 4.95 | 0.007 | 209.5 |
| 2×6 | 0.8 | 13.4 | 3.3 | 0.006 | 263.2 |
3. Application
- communication audio frequency
- broadcast sound system
- electric equipment and automatic equipment
- anti-interference needed circuit shielded wire and cable
4. Product Image
Product Advantage
Product Package
5. Product standard
JB/T 8734.5, IEC 60227,BS 6500,BS EN 50525,VDE 0281
6. Company certificate
ISO9001, ISO14001, OHSAS18001, CCC, CE, CB, RoHS, China TOP 100 Enterprises in Cables industry, Guangdong TOP 20 Enterprises in Cables industry and others.
