1KV copper conductor XLPE insulation and LSOH sheath fixed application power cable

1KV copper conductor XLPE insulation and LSOH sheath fixed application power cable image

Get a Quote Email to us

Brand Name :
CHINT

Model Number :
LSZH(WDZR-YJY22)

Certification :
CE/SGS/KEMA

Place of Origin :
CHINA

MOQ :
Negotiable

Price :
Negotiable

Supply Ability :
500km/month

Packaging Details :
Wooden drum/iorn drum

Marking :
Embossing or printing

Armored :
Double steel tape

Core :
1/2/3/4/5 & 2+1/3*1/4+1/3+2

Core identification :
red /yellow /green /blue /black or Y/G

Conductor shape :
Compacted round or sector

Binding :
Flame retardant no –woven tape

1KV copper conductor XLPE insulation and LSOH sheath fixed application power cable

Detailed Product Description

Constructions

Conductor : Plain annealed copper solid or stranded (class 1 or 2) conductor complying with BS EN 60228

Insulation : XLPE(cross-linked polyethylene) rated at 90 ℃

Interlining: LSOH Flame Retardant Polyolefin, black

Armouring: STA(Steel-Tape Armouring)

Sheath : LSOH Flame Retardant Polyolefin, black

Certificates

CE, SGS, KEMA and more others at request

Standards

International: IEC 60502, IEC 60228, IEC 60332, IEC 60754

China: GB∕T 12706.1-2008, GB∕T 19666-2005

Other standards such as BS,VDE and ICEA upon request

Technical data

Rated voltage: 0.6/1 kV

Maximum Conductor Temperature: under normal (90 ℃), emergency (130℃) or short circuit no more than 5 s (250℃) conditions.

Min. Ambient Temp.: The cable shall be pre heated if the ambient temperature is below 0℃

Min. Bending Radius: single core cable 20(d+D)±5%

Multi-core cable 15(d+D)±5%

Note:

Insulation identification as per standards or customer requirement

Applications

Laying in room ,tunnel ,cable trench ,and pipes.

Product Description

Designed for fixed power and control applications where mechanical protection is not required. Suitable for use indoors, outdoors or laid in concrete but not for direct burial or immersion in water LSZH cables ensure increased safety in the case of fire due to the virtual elimination of toxic fumes if burnt. Pronounced advantages when compared to PVC cabling: low fire load, low smoke emission reduced fire propagation.

Application

These power cables are used for electricity supply in low voltage installation system. They are well adapted to underground use in industrial applications with an additional mechanical protection.These cables can be fixed on cable trays, within conduits or fixed to walls.

Used in energy networks refineries, mines, hotels, schools, tunnels, high constructions, hospitals, power plants, data processing centers, business centers where there is a risk of fire

Technical Specifications

Nom. Cross-section of conductor	Strands No./Dia. Of Conductor	Insulation Thickness	Thickness of steel tape	Sheath Thickness	Approx. O.D.	Approx.	Max. D.C Resistance of Conductor (20 ℃)	Testing Voltage A.C	Current Rating
Nom. Cross-section of conductor	Strands No./Dia. Of Conductor	Insulation Thickness	Thickness of steel tape	Sheath Thickness	Approx. O.D.	Weight	Max. D.C Resistance of Conductor (20 ℃)	Testing Voltage A.C	In air (A)	In soil(A)
1×10	7/1.33	0.7	0.2	1.8	11.8	265	1.83	3.5	77	94
1×16	7/1.67	0.7	0.2	1.8	12.8	338	1.15	3.5	100	120
1×25	7/2.10	0.9	0.2	1.8	14.5	458	0.727	3.5	130	155
1×35	7/2.48	0.9	0.2	1.8	15.6	571	0.524	3.5	160	185
1×50	10/2.56	1.0	0.2	1.8	16.8	712	0.387	3.5	195	220
1×70	14/2.56	1.1	0.2	1.8	18.7	940	0.268	3.5	245	270
1×95	19/2.56	1.1	0.2	1.8	20.3	1209	0.193	3.5	300	320
1×120	24/2.56	1.2	0.2	1.8	22.0	1465	0.153	3.5	349	365
1×150	30/2.56	1.4	0.2	1.8	23.8	1757	0.124	3.5	400	410
1×185	37/2.56	1.6	0.2	1.8	25.9	2157	0.0991	3.5	465	465
1×240	48/2.58	1.7	0.2	1.8	28.3	2732	0.0754	3.5	550	540
1×300	60/2.58	1.8	0.2	1.9	30.9	3344	0.0601	3.5	635	610
1×400	60/2.93	2.0	0.2	2	34.4	4260	0.047	3.5	745	695
1×500	60/3.33	2.2	0.5	2.2	39.6	5673	0.0366	3.5	860	780
1×630	60/3.76	2.4	0.5	2.3	44.0	7133	0.0283	3.5	990	880
2×1.5	1/1.38	0.7	0.2	1.8	12.3	230	12.1	3.5	20	31
2×2.5	1/1.76	0.7	0.2	1.8	13.1	266	7.56	3.5	27	41
2×4	1/2.23	0.7	0.2	1.8	14.0	316	4.61	3.5	35	53
2×6	1/2.74	0.7	0.2	1.8	15.0	378	3.08	3.5	45	66
2×10	7/1.33	0.7	0.2	1.8	17.5	516	1.83	3.5	63	90
2×16	7/1.67	0.7	0.2	1.8	19.5	672	1.15	3.5	84	117
2×25	7/2.10	0.9	0.2	1.8	22.9	937	0.727	3.5	113	151
2×35	7/2.48	0.9	0.2	1.8	25.2	1181	0.524	3.5	139	181
2×50	10/2.56	1.0	0.2	1.8	21.8	1281	0.387	3.5	161	210
2×70	14/2.56	1.1	0.2	1.9	24.8	1734	0.268	3.5	204	257
2×95	19/2.56	1.1	0.2	2	27.5	2278	0.193	3.5	252	310
2×120	24/2.56	1.2	0.5	2.2	31.3	3095	0.153	3.5	291	351
2×150	30/2.56	1.4	0.5	2.3	34.5	3730	0.124	3.5	333	393
2×185	37/2.56	1.6	0.5	2.5	38.2	4618	0.0991	3.5	385	445
2×240	48/2.56	1.7	0.5	2.6	42.2	5832	0.0754	3.5	457	516
2×300	60/2.56	1.8	0.5	2.8	46.3	7142	0.0601	3.5	527	583
3×1.5	1/1.38	0.7	0.2	1.8	12.7	256	12.1	3.5	20	31
3×2.5	1/1.76	0.7	0.2	1.8	13.5	302	7.56	3.5	27	41
3×4	1/2.23	0.7	0.2	1.8	14.6	367	4.61	3.5	35	53
3×6	1/2.74	0.7	0.2	1.8	15.7	449	3.08	3.5	45	66
3×10	7/1.33	0.7	0.2	1.8	18.4	627	1.83	3.5	63	90
3×16	7/1.67	0.7	0.2	1.8	20.5	838	1.15	3.5	84	117
3×25	7/2.10	0.9	0.2	1.8	24.2	1191	0.727	3.5	113	151
3×35	7/2.48	0.9	0.2	1.8	26.6	1528	0.524	3.5	139	181
3×50	10/2.56	1.0	0.2	1.9	25.5	1814	0.387	3.5	161	210
3×70	14/2.56	1.1	0.2	2	29.0	2474	0.268	3.5	204	257
3×95	19/2.56	1.1	0.5	2.1	33.5	3598	0.193	3.5	252	310
3×120	24/2.56	1.2	0.5	2.3	36.7	4386	0.153	3.5	291	351
3×150	30/2.56	1.4	0.5	2.4	40.7	5332	0.124	3.5	333	393
3×185	37/2.56	1.6	0.5	2.5	44.6	6562	0.0991	3.5	385	445
3×240	48/2.56	1.7	0.5	2.8	50.2	8414	0.0754	3.5	457	516
3×300	60/2.56	1.8	0.5	2.9	54.9	10306	0.0601	3.5	527	583
4×1.5	1/1.38	0.7	0.2	1.8	13.5	291	12.1	3.5	20	31
4×2.5	1/1.76	0.7	0.2	1.8	14.4	348	7.56	3.5	27	41
4×4	1/2.23	0.7	0.2	1.8	15.5	430	4.61	3.5	35	53
4×6	1/2.74	0.7	0.2	1.8	16.7	534	3.08	3.5	45	66
4×10	7/1.33	0.7	0.2	1.8	19.8	758	1.83	3.5	63	90
4×16	7/1.67	0.7	0.2	1.8	22.2	1027	1.15	3.5	84	117
4×25	7/2.10	0.9	0.2	1.8	26.3	1479	0.727	3.5	113	151
4×35	7/2.48	0.9	0.2	1.8	29.1	1914	0.524	3.5	139	181
4×50	10/2.56	1.0	0.2	2	28.4	2334	0.387	3.5	161	210
4×70	14/2.56	1.1	0.5	2.1	33.6	3518	0.268	3.5	204	257
4×95	19/2.56	1.1	0.5	2.3	37.9	4638	0.193	3.5	252	310
4×120	24/2.56	1.2	0.5	2.4	41.8	5701	0.153	3.5	291	351
4×150	30/2.56	1.4	0.5	2.6	46.0	6912	0.124	3.5	333	393
4×185	37/2.56	1.6	0.5	2.7	51.0	8562	0.0991	3.5	385	445
4×240	48/2.56	1.7	0.5	3	57.7	11052	0.0754	3.5	457	516
4×300	60/2.56	1.8	0.5	3.1	62.7	13479	0.0601	3.5	527	583
5×1.5	1/1.38	0.7	0.2	1.8	14.3	328	12.1	3.5	20	31
5×2.5	1/1.76	0.7	0.2	1.8	15.3	397	7.56	3.5	27	41
5×4	1/2.23	0.7	0.2	1.8	16.6	497	4.61	3.5	35	53
5×6	1/2.74	0.7	0.2	1.8	18.0	623	3.08	3.5	45	66
5×10	7/1.33	0.7	0.2	1.8	21.4	895	1.83	3.5	63	90
5×16	7/1.67	0.7	0.2	1.8	24.1	1225	1.15	3.5	84	117
5×25	7/2.10	0.9	0.2	1.8	28.7	1780	0.727	3.5	113	151
5×35	7/2.48	0.9	0.2	1.9	31.9	2329	0.524	3.5	139	181
5×50	19/1.86	1.0	0.2	2.1	31.9	2879	0.387	3.5	161	210
5×70	14/2.56	1.1	0.5	2.2	37.8	4327	0.268	3.5	204	257
5×95	19/2.56	1.1	0.5	2.4	42.8	5740	0.193	3.5	252	310
5×120	24/2.56	1.2	0.5	2.5	46.8	7027	0.153	3.5	291	351
5×150	30/2.56	1.4	0.5	2.7	52.1	8591	0.124	3.5	333	393
5×185	37/2.56	1.6	0.5	2.9	57.5	10636	0.0991	3.5	385	445
5×240	48/2.56	1.7	0.5	3.2	64.5	13651	0.0754	3.5	457	516
5×300	60/2.56	1.8	0.5	3.4	71.0	16764	0.0601	3.5	527	583
3×2.5+1×1.5	1/1.76	0.7	0.2	1.8	14.1	334	7.56	3.5	27	41
3×4+1×2.5	1/2.23	0.7	0.2	1.8	15.2	410	4.61	3.5	35	53
3×6+1×4	1/2.74	0.7	0.2	1.8	16.4	508	3.08	3.5	45	66
3×10+1×6	7/1.33	0.7	0.2	1.8	19.0	701	1.83	3.5	63	90
3×16+1×10	7/1.67	0.7	0.2	1.8	21.6	959	1.15	3.5	84	117
3×25+1×16	7/2.10	0.9	0.2	1.8	25.3	1365	0.727	3.5	113	151
3×35+1×16	7/2.48	0.9	0.2	1.8	27.4	1689	0.524	3.5	139	181
3×50+1×25	10/2.56	1.0	0.2	1.9	27.9	2115	0.387	3.5	161	210
3×70+1×35	14/2.56	1.1	0.2	2	32.1	2896	0.268	3.5	204	257
3×95+1×50	19/2.56	1.1	0.5	2.2	37.4	4213	0.193	3.5	252	310
3×120+1×70	24/2.56	1.2	0.5	2.3	41.4	5251	0.153	3.5	291	351
3×150+1×70	30/2.56	1.4	0.5	2.4	45.0	6175	0.124	3.5	333	393
3×185+1×95	37/2.56	1.6	0.5	2.6	50.0	7731	0.0991	3.5	385	445
3×240+1×120	48/2.56	1.7	0.5	2.8	56.0	9857	0.0754	3.5	457	516
3×300+1×150	60/2.56	1.8	0.5	3	61.3	12042	0.0601	3.5	527	583
3×2.5+2×1.5	1/1.76	0.7	0.2	1.8	14.9	369	7.56	3.5	27	41
3×4+2×2.5	1/2.23	0.7	0.2	1.8	16.1	457	4.61	3.5	35	53
3×6+2×4	1/2.74	0.7	0.2	1.8	17.4	573	3.08	3.5	45	66
3×10+2×6	7/1.33	0.7	0.2	1.8	20.0	785	1.83	3.5	63	90
3×16+2×10	7/1.67	0.7	0.2	1.8	23.0	1092	1.15	3.5	84	117
3×25+2×16	7/2.10	0.9	0.2	1.8	26.8	1556	0.727	3.5	113	151
3×35+2×16	7/2.48	0.9	0.2	1.8	28.7	1874	0.524	3.5	139	181
3×50+2×25	10/2.56	1.0	0.2	2	29.1	2384	0.387	3.5	161	210
3×70+2×35	14/2.56	1.1	0.5	2.1	34.4	3583	0.268	3.5	204	257
3×95+2×50	19/2.56	1.1	0.5	2.3	38.5	4692	0.193	3.5	252	310
3×120+2×70	24/2.56	1.2	0.5	2.4	42.5	5909	0.153	3.5	291	351
3×150+2×70	30/2.56	1.4	0.5	2.5	46.8	6889	0.124	3.5	333	393
3×185+2×95	37/2.56	1.6	0.5	2.7	52.5	8744	0.0991	3.5	385	445
3×240+2×120	48/2.56	1.7	0.5	2.9	58.5	11068	0.0754	3.5	457	516
3×300+2×150	60/2.56	1.8	0.5	3.1	64.5	13551	0.0601	3.5	527	583
4×2.5+1×1.5	1/1.76	0.7	0.2	1.8	15.1	383	7.56	3.5	27	41
4×4+1×2.5	1/2.23	0.7	0.2	1.8	16.4	477	4.61	3.5	35	53
4×6+1×4	1/2.74	0.7	0.2	1.8	17.7	598	3.08	3.5	45	66
4×10+1×6	7/1.33	0.7	0.2	1.8	20.7	839	1.83	3.5	63	90
4×16+1×10	7/1.67	0.7	0.2	1.8	23.5	1159	1.15	3.5	84	117
4×25+1×16	7/2.10	0.9	0.2	1.8	27.7	1667	0.727	3.5	113	151
4×35+1×16	7/2.48	0.9	0.2	1.9	30.4	2107	0.524	3.5	139	181
4×50+1×25	10/2.56	1.0	0.2	2	29.5	2590	0.387	3.5	161	210
4×70+1×35	14/2.56	1.1	0.5	2.2	35.0	3900	0.268	3.5	204	257
4×95+1×50	19/2.56	1.1	0.5	2.3	39.3	5144	0.193	3.5	252	310
4×120+1×70	24/2.56	1.2	0.5	2.5	43.2	6386	0.153	3.5	291	351
4×150+1×70	30/2.56	1.4	0.5	2.6	48.3	7683	0.124	3.5	333	393
4×185+1×95	37/2.56	1.6	0.5	2.8	53.2	9566	0.0991	3.5	385	445
4×240+1×120	48/2.56	1.7	0.5	3	59.7	12219	0.0754	3.5	457	516
4×300+1×150	60/2.56	1.8	0.5	3.3	65.6	14985	0.0601	3.5	527	583

PACKAGING&SHIPPING

Different package for customer choose !

Our electrical cable export packing is specially made to ensure that the quality of the products will be not affected during the transportation. Our electrical cable is using electrical cable wheel for the packing, the wheel can be all steel, steel frame and fumigated wood, or fumigated wooden cases. We are using different packing for different length of the cable, to ensure there will be no problem during the delivery of the products.

1. If the diameter of the wheel is longer than 2 meters, we are using all steel wheel to pack the products

2. If the diameter of the wheel is between 1.4meters to 1.8meters, we are using steel frame and fumigated wood to pack the products.

3. If the diameter of the wheel is less than 1.4meters, we will use the fumigated wooden wheel to pack the products

4. For the packing of the electrical wires and small quantity of cables, we will use the fumigated wooden box to pack.

Product photo

We are China 1KV copper conductor XLPE insulation and LSOH sheath fixed application power cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.

1KV copper conductor XLPE insulation and LSOH sheath fixed application power cable
