1 KV PE Insulated Aerial Bunch XLPE Insulated Power Cable 5 Cores With Neutral Conductor
1 KV PE Insulated Aerial Bunch XLPE Insulated Power Cable 5 Cores With Neutral Conductor image
Brand Name :SHANCABLE
Model Number :ABC-AL/PE-0.6/1KV 5 Cores
Certification :ISO,CE,IEC,TUV,KEMA
Place of Origin :Shanghai, China
MOQ :Negotiable
Price :Negotiable
Payment Terms :L/C, T/T
Supply Ability :100KM/Week
Delivery Time :10 Days
Packaging Details :Wooden Drum
Phase Conductor :Aluminium
Neutral Conductor :Aluminum Alloy
Insulation :PE
Cores No. :5
Rated Voltage :0.6/1 KV
Application :Aerial Electrics Transmitting
PE Insulation Five Core Aerial Drop Cable STANDARD NF C 33-209 NFA 2X
Construction
- Conductor:
a)Phase – The phase conductor shall be of H68 Condition aluminium conductor and compacted circular stranded.
b)Neutral or messenger – The Neutral or messenger conductor shall be of aluminium alloy conductor and compacted circular stranded c)Street Lighting- The street lighting conductors shall be of H68 condition aluminium conductor and compacted circular stranded..
- Insulation:
The phase, neutral conductors shall be extruded with polyethylene(PE) as insulation.
Schedule of technical particulars
| Phase conductor | |||||||||
| Nominal cross-sectional area | mm² | 25 | 35 | 50 | 70 | 95 | 120 | 150 | 185 |
| Number of cores | 3 | 3 | 3 | 3 | 3 | 3 | 3 | 3 | |
| Minimum number of wires | 6 | 6 | 6 | 12 | 15 | 15 | 30 | 30 | |
| Nominal insulation thickness | mm | 1.2 | 1.2 | 1.4 | 1.4 | 1.6 | 1.6 | 1.8 | 2.0 |
| Diameter of insulated core | mm | 8.5 | 9.5 | 11.2 | 13.0 | 15.1 | 16.6 | 18.4 | 20.6 |
| Max. DC resistance at 20℃ | ohm/km | 1.20 | 0.868 | 0.641 | 0.443 | 0.320 | 0.253 | 0.206 | 0.164 |
| Current rating at still wind, ambient | A | 84 | 104 | 129 | 167 | 209 | 246 | 283 | 332 |
| temperature=30℃ | |||||||||
| Conductor temperature=75℃ | |||||||||
| Messenger conductor | |||||||||
| Nominal cross-sectional area | mm² | 25 | 25 | 35 | 50 | 70 | 70 | 95 | 120 |
| Minimum number of wires | 6 | 6 | 6 | 6 | 12 | 12 | 15 | 15 | |
| Nominal insulation thickness | mm | 1.2 | 1.2 | 1.2 | 1.4 | 1.4 | 1.4 | 1.6 | 1.6 |
| Diameter of insulated core | mm | 8.5 | 8.5 | 9.5 | 11.2 | 13.1 | 13.1 | 15.1 | 16.6 |
| Max. DC resistance at 20℃ | ohm/km | 1.312 | 1.312 | 0.943 | 0.693 | 0.469 | 0.469 | 0.349 | 0.273 |
| Calculated breaking load | kN | 6.4 | 6.4 | 8.9 | 12.1 | 18.0 | 18.0 | 24.2 | 30.8 |
| Street lighting conductor | |||||||||
| Nominal cross-sectional area | mm² | 25 | 25 | 35 | 50 | 70 | 70 | 95 | 120 |
| Minimum number of wires | 6 | 6 | 6 | 6 | 12 | 12 | 15 | 15 | |
| Nominal insulation thickness | mm | 1.2 | 1.2 | 1.2 | 1.4 | 1.4 | 1.4 | 1.6 | 1.6 |
| Diameter of insulated core | mm | 8.5 | 8.5 | 9.5 | 11.2 | 13.1 | 13.1 | 15.1 | 16.6 |
| Max. DC resistance at 20℃ | ohm/km | 1.312 | 1.312 | 0.943 | 0.693 | 0.469 | 0.469 | 0.349 | 0.273 |
| Completed cable | |||||||||
| Approx. overall diameter | mm | 23.2 | 25.6 | 30.0 | 34.9 | 40.6 | 44.1 | 49.2 | 54.9 |
| Approx. weight of cable | kg/km | 470 | 560 | 740 | 980 | 1330 | 1580 | 1940 | 2410 |
| Packing length | m/drum | 1000 | 1000 | 1000 | 1000 | 500 | 500 | 500 | 500 |
STANDARD NF C 33-209
NFA 2X
| Phases | Neutral/Messenger | ||||||||
| Distribution Lines | Pub. Lighting | ||||||||
| Cable Type | Number of | Number of | Avarage | Resistance | Conductance | Number of | Avarage | Rated | Resistance |
| core | wire | diameter | at 20℃ | at 30℃ | core | diameter | Strength | at 20℃ | |
| mm² | mm² | PCS | mm | ohm/km | A | mm² | mm | kN | ohm/km |
| 2×16 | 2×16 | 7 | 4.6 | 1.91 | 93 | – | – | – | – |
| 2×35 | 2×35 | 7 | 5.9 | 1.20 | 122 | – | – | – | – |
| 2×35 | 2×35 | 7 | 6.9 | 0.868 | 129 | – | – | – | – |
| 2×50 | 2×50 | 7 | 8.1 | 0.641 | 158 | – | – | – | – |
| 4×16 | 4×16 | 7 | 4.6 | 1.91 | 83 | – | – | – | – |
| 4×25 | 4×25 | 7 | 5.9 | 1.20 | 111 | – | – | – | – |
| 4×35 | 4×35 | 7 | 6.9 | 0.868 | 131 | – | – | – | – |
| 3×25+54.6 | 3×25 | 7 | 5.9 | 1.20 | 112 | – | 9.6 | 16.0 | 0.63 |
| 3×25+1×16+54.6 | 3×25 | 7 | 5.9 | 1.20 | 112 | 1×16 | 9.6 | 16.0 | 0.63 |
| 3×25+2×16+54.6 | 3×25 | 7 | 5.9 | 1.20 | 112 | 2×16 | 9.6 | 16.0 | 0.63 |
| 3×35+54.6 | 3×35 | 7 | 6.9 | 0.868 | 138 | – | 9.6 | 16.0 | 0.63 |
| 3×35+1×16+54.6 | 3×35 | 7 | 6.9 | 0.868 | 138 | 1×16 | 9.6 | 16.0 | 0.63 |
| 3×35+2×16+54.6 | 3×35 | 7 | 6.9 | 0.868 | 138 | 2×16 | 9.6 | 16.0 | 0.63 |
| 3×50+54.6 | 3×50 | 7 | 8.1 | 0.641 | 168 | – | 9.6 | 16.0 | 0.63 |
| 3×50+1×16+54.6 | 3×50 | 7 | 8.1 | 0.641 | 168 | 1×16 | 9.6 | 16.0 | 0.63 |
| 3×50+2×16+54.6 | 3×50 | 7 | 8.1 | 0.641 | 168 | 2×16 | 9.6 | 16.0 | 0.63 |
| 3×70+54.6 | 3×70 | 12 | 9.7 | 0.443 | 213 | – | 9.6 | 16.0 | 0.63 |
| 3×70+1×16+54.6 | 3×70 | 12 | 9.7 | 0.443 | 213 | 1×16 | 9.6 | 16.0 | 0.63 |
| 3×70+2×16+54.6 | 3×70 | 12 | 9.7 | 0.443 | 213 | 2×16 | 9.6 | 16.0 | 0.63 |
| 3×70+1×25+54.6 | 3×70 | 12 | 9.7 | 0.443 | 213 | 1×25 | 9.6 | 16.0 | 0.63 |
| 3×70+2×25+54.6 | 3×70 | 12 | 9.7 | 0.443 | 213 | 2×25 | 9.6 | 16.0 | 0.50 |
| 3×70+70 | 3×70 | 12 | 9.7 | 0.443 | 213 | – | 10.2 | 20.6 | 0.50 |
| 3×70+1×16+70 | 3×70 | 12 | 9.7 | 0.443 | 213 | 1×16 | 10.2 | 20.6 | 0.50 |
| 3×70+2×16+70 | 3×70 | 12 | 9.7 | 0.443 | 213 | 2×16 | 10.2 | 20.6 | 0.50 |
| 3×95+70 | 3×95 | 12 | 11.5 | 0.320 | 258 | – | 10.2 | 20.6 | 0.50 |
| 3×95+1×16+70 | 3×95 | 12 | 11.5 | 0.320 | 258 | 1×16 | 10.2 | 20.6 | 0.50 |
| 3×95+2×16+70 | 3×95 | 12 | 11.5 | 0.320 | 258 | 2×16 | 10.2 | 20.6 | 0.50 |
| 3×120+70 | 3×120 | 12 | 12.8 | 0.253 | 300 | – | 10.2 | 20.6 | 0.50 |
| 3×120+1×16+70 | 3×120 | 19 | 12.8 | 0.253 | 300 | 1×16 | 10.2 | 20.6 | 0.50 |
| 3×120+2×16+70 | 3×120 | 19 | 12.8 | 0.253 | 300 | 2×16 | 10.2 | 20.6 | 0.50 |
| 3×150+70 | 3×150 | 19 | 14.5 | 0.206 | 344 | – | 10.2 | 20.6 | 0.50 |
| 3×150+1×16+70 | 3×150 | 19 | 14.5 | 0.206 | 344 | 1×16 | 10.2 | 20.6 | 0.50 |
| 3×150+2×16+70 | 3×150 | 19 | 14.5 | 0.206 | 344 | 2×16 | 10.2 | 20.6 | 0.50 |
| 3×120+95 | 3×120 | 19 | 12.8 | 0.253 | 300 | – | 12.9 | 27.9 | 0.343 |
| 3×120+1×16+95 | 3×120 | 19 | 12.8 | 0.253 | 300 | 1×16 | 12.9 | 27.9 | 0.343 |
| 3×120+2×16+95 | 3×120 | 19 | 12.8 | 0.253 | 300 | 2×16 | 12.9 | 27.9 | 0.343 |
| 3×150+95 | 3×150 | 19 | 14.5 | 0.206 | 344 | – | 12.9 | 27.9 | 0.343 |
| 3×150+1×16+95 | 3×150 | 19 | 14.5 | 0.206 | 344 | 1×16 | 12.9 | 27.9 | 0.343 |
| 3×150+2×16+95 | 3×150 | 19 | 14.5 | 0.206 | 344 | 2×16 | 12.9 | 27.9 | 0.343 |
We are China 1 KV PE Insulated Aerial Bunch XLPE Insulated Power Cable 5 Cores With Neutral Conductor manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
